TRAFFIC Light Control System 🚦🤖 | PLC Programming Tutorial for Beginners | Udemy PLC project

Описание: 🔧 In this video, we design and simulate a PLC-based Traffic Light Control System for a 4-way intersection using ladder logic and timers! Ideal for engineering students, beginners, and anyone learning PLC programming and real-world automation logic.

🎯 Project Features:
• Simulates a full 4-way intersection control with GREEN, YELLOW, RED lights 🚦
• Full cycle of timed light changes (40s, 5s, 20s, 5s)
• Uses START and STOP buttons to begin and halt the system instantly 🟢⛔
• Built entirely with ladder logic and PLC timers 🪜⏱️
• Demonstrates real-world traffic control automation

🛠️ Cycle Breakdown:
1️⃣ Green A for 40s, Red B stays ON
2️⃣ Yellow A for 5s, Red B continues
3️⃣ Red A + Green B for 20s
4️⃣ Red A + Yellow B for 5s
5️⃣ Cycle repeats with Green A again
🚨 STOP button halts everything at any point!

Perfect for your next PLC project or automation class demo. Watch the full implementation and logic explanation in this hands-on tutorial! 💡
+++++++++++++++++++++++++++++++
⏱️ Chapters:
00:00 – Introduction to the Traffic Light Project 🚦
00:30 – System Overview & Sequence Explanation 🧩
01:20 – PLC Inputs, Outputs & Timer Setup 🪜
02:35 – Step 1: Green A / Red B – 40s ⏱️
03:10 – Step 2: Yellow A / Red B – 5s ⚠️
03:45 – Step 3: Red A / Green B – 20s ✅
04:20 – Step 4: Red A / Yellow B – 5s ⚠️
04:55 – Cycle Repeat Logic ♻️
05:30 – STOP Button Logic ⛔
06:15 – Final Simulation Test 🎥
07:10 – Wrap-Up & Tips for Students 🎓
++++++++++++++++++++++++++
