Nemesis Mini Quad: The Unboxing

Описание: A great new project here guys....
Get it here:
-(Buzz Hobbies) http://www.buzzhobbies.com.au/index.....
-(R-Squared market) https://squareup.com/market/rsquared-...
-(R-Squared Site)http://www.rsquared-innovations.com/f...
-(USA Seller) Quadrysteria http://www.quadrysteria.com/nemesis-2...
-(Asia/Europe) Drone Matters http://www.dronematters.com/
-(USA Seller) GetFPV http://www.getfpv.com/nemesis-240-mi....
-(USA Seller) GetFPV http://www.getfpv.com/nemesis-240-mi....
-(USA Seller) Multirotor Superstore http://www.multirotorsuperstore.com/....
-(USA Seller) Amain Hobbies http://www.amain.com/product_info.ph....
-(USA Seller) TMARC1 Hobby https://tmkarc1hobby.com/pre-order-n....
-(USA Seller) TMARC1 Hobby https://tmkarc1hobby.com/pre-order-n....
Pricing :
G-10: $121
Full Carbon Fiber 3k twill weave: $144

Weight
G10 (149g)
CF (128g)

Standard Frame features:
-Vibration free separated Clean and Dirty sections for smooth video recording
-Instantly fully inward fold-able quad for easy pack and go and crash protection
-Lightweight frame design but still able to take hard hits
-Unique custom folding and extending arm mechanism allows both 5" and 6" props
-4 predefined flight configurations for wings, X compact, H compact, X extended, Superman
-Alignment/locking holes for H in 5", X in 5", X in 6"
-Unique ability to dirty or clean mount your flight controller (supports 45mm and below FCs)
-2 Stage Bobbin travel limiter
-Built in Mobius/GoPro1-3+ mounts integrated into frame and accessories
-Dedicated Board Camera and rear bulkhead plates
-Accessory Shelf with 3 mounting positions, (you can use up to 3 at once)
-Extension plate for mounting Mobius, GoPro, InfinityCam One, CCD flight cam out front, bolts in 2 locations
-Multiple SMA jack mounts including a unique rear bulkhead mount
-Extended lower front spoiler on dirty section for frontal crash impact absorption
-Intelligent Electronics management: tons of options for mounting electronics including Buzzers, Strobes, leds, voltage readers, OSD, access Mobius buttons when mounted inside frame, etc
-Clean wiring, all ESCs mount inside center frame as well as flight controller, fits Bt408 mini PDB perfectly inside
-Battery can be top mounted or mounted inside the clean section
-Integrated mounting points (2 locations) for Landing Gear/Standoffs
-Optional upgrades TBA later

The standard frame kit includes:
-1 Top Clean Plate (1mm)
-1 Bottom Clean Plate (1mm)
-1 Top Dirty Plate (1.5mm)
-1 Bottom Dirty Plate (1.5mm)
-4 Adjustable extending Arms (3mm)
-1 CCD Camera Plate (1mm)
-1 Rear Bulkhead Plate (1mm)
-1 Stacking Accessory Shelf/Plate (1mm)
-1 Camera front Extension Plate (1.5mm)
-All hardware required to assemble frame

4 x M4x14mm (arms)
4 x M4 Nylock Nuts (arms)
4 x M2X10mm (Dirty Section)
4 x M2 Standard or Nylock Nuts (dirty section)
4 x High Quality Vibration Dampers
8 x M3 Standard Nuts (bobbins)
16 x M3x6 or M3x8 button head (clean section)
8 x M3x35mm standoffs (clean section)
4 x M2x3mm spacers (dirty section)

Recommended Equipment:
Motors: Sunnysky x2204 2300kv (3s), Tiger MN 1806 2300kv (3s-4s) , Cobra 2204 2300kv (3s), Cobra 2204 1960kv (4s)
ESC: Blue Series 12A (Simonk 05-13 FW), Turnigy plush 10A on BLheli
Prop: 2 blade 5030 Gemfan, 2 Blade 5 x 4 HQ Composite, 2 Blade 6030 HQ Composite
Flight Controller: Flip 1.5/Ez, Naze32 Acro, OP CC3D, KK2 (can also fit but large for a mini)
Camera: PZ0420 ccd, any bracket camera as well
PDB: bt408 Mini PDB (6g) w/ integrated video filtering

Instruction Manual: http://www.amain.com/images/Link%20Im...
