FMARK2 perforacinis ploteriavimas / failo paruošimas ir rezultatas

Описание: Graphtec F-MARK2 perforacinis ploteriavimas. Viskas pažingsniui nuo failo paruošimo iki rezultato.
FMARK2:    • Graphtec FMARK2 - automatinė sistema lapin...
CE7000-40:    • Graphtec CE7000 ploteriai (INTRO)
--------------------------------------------------
The F-MARK2 Automatic Sheet Feeder Unit, working in bundle with Graphtec CE7000-40 cutter, is designed to automatically feed and contour cut media size up to 500 mm x 370mm without the need for an operator. An arm with air suction cups lifts the media from the supply tray and places it in the cutter. Included I-MARK PLUS Software and CCD Camera accurately align media for contour / perforation cutting of pre-printed graphics - efficiently freeing up labor to work on other tasks. Once completed, each sheet neatly falls into the Exit Tray. Additional sheets of the same design can be loaded during cutting without resending the job from a computer, further enhancing productivity.
Learn more about Graphtec FMARK2: https://www.graphtecamerica.com/f-mark2
Learn more about Graphtec CE7000-40: https://www.graphtecamerica.com/ce7000
FMARK2 can handle up to 200 sheets (depend on the thickness) of media in a continuous cycle but with the ability to add further sheets as required without interrupting the cutting process. This is a capability that we consider sets the F-Mark2 Automatic Sheet Feeder apart from any comparable sheet-fed system.
450 Grams of down force enable users to produce small and medium size runs of: labels, business cards, heat transfer apparel, and more. Using Adobe Illustrator and CorelDraw EPS file types, simply add registration marks to your design and import to the iMark Plus Software for fast, high quality results.
I-MARK Plus software: number of copies, force, speed, offset, paths, camera angle and feed-in line control, save params
• Continuous, HAND-FREE sheet media loading & processing
• Dedicated software ensures ACCURATE alignment
• CCD CAMERA quickly scans 2-point registration marks
• CONTOUR AND PERFORATED CUTTING of printed graphics
• Add additional sheets to the feeder WITHOUT RESENDING the job
CE7000-40 basic specifications:
• Maximum cutting speed: 600 mm/s
• Maximum cutting force: 450 g
• Max force: 450g
• Fmark2 used interface: USB 2.0
• 772 x 292 x 313 mm / 13 kg
F-MARK2 auto-feeder basic specifications:
• Supported sheets: A4, SRA4, A3, A3+, SRA3
• Supply tray: max 35mm high or 200 sheets
• Max sheet: 370 mm x 500 mm
• Mark detection: CCD Camera
• 500 × 600 × 225 mm / 14 kg
