What are PCB stackups?
Автор: Siemens Software
Загружено: 2023-11-14
Просмотров: 647
Описание:
A PCB stackup is the foundation of any PCB design. It is the range of copper and non-conductive material that is arranged in a specific order and manufactured by heat and pressed, that produces the foundation intricacies of a PCB design. A good PCB stackup enables the highest potential for the PCB to perform as expected or better.
0:07 What are PCB stackups?
0:26 What does a PCB stack up consist of?
1:32 Why is the PCB stackup important?
2:14 Why do we need good PCB stackups?
2:45 What is the value of having a good PCB stackup?
