[ $7 ] DIY modular synth Dual VCA V2164 IC based / compatible SSI2164 , SSM2164 , AS2164
Автор: HAGIWO
Загружено: 2021-07-06
Просмотров: 4082
Описание:
My 24th original eurorack modular synth DIY projects.
Dual VCA module with V2164 VCA IC .( compatible SSI2164,SSM2164,AS2164 )
This time it's an analog circuit, not a digital one.
It can also be used as a send / return for a guitar pedal.
0:00 sound example
0:20 introduction
1:40 send / return for guitar pedal ( JOYO atmosphere reverb )
2:34 specification and schematics
4:17 development power module
working documents ( Source code )
https://note.com/solder_state/n/n14a8...
Please support me to continue projects.
/ hagiwo
Envelope generator rev2 video
• [ $5 ] DIY modular synth Envelope Generato...
YAMAHA FM VCO video ( use with reverb pedal )
• [ $35 ] DIY eurorack modular synth YAMAHA ...
Review of JOYO atmosphere reverb pedal
• Видео
-------------------------------------------------------------
See Instagram and Twitter for the development status of my next module.
Instagram
/ hagiwo_1
Twitter
/ hagiwo1
-------------------------------------------------------------
