Changing the Supercharger Drive Belt on the 2022+ Kawasaki Ultra 310 JetSki

Описание: JD's tutorial on removing the Supercharger drive belt on 2022+ Kawasaki Ultra 310 Series JetSkis.

The process is fairly involved and there are a few components that must be removed from the ski in order to complete this process.

There are different ways to complete this maintenance, but the way portrayed in the video is the way that I do it.

See my “Supercharger Tensioner and Belt” video along with my “exhaust filter” video for a detailed look at what else needs to be done to complete this process.

This is provided for demonstration purposes only, please consult a professional mechanic.



00:00 Intro
00:12 Replacing The Supercharger Belt
00:40 Scope of Project
01:03 Parts that need to be removed
03:46 Remove (2) 10mm bolts and hoses on oil catch can
04:13 Inspecting the old belt
04:51 Remove (2) 12mm intercooler bolts
04:57 Loosen hose clamps and remove air ducts from intercooler,bov, and relief valve
05:45 Removing the Exhaust Muffler Pipe Assy. And Exhaust filter
06:04 Remove (4) 14mm exhaust bolts, (2) hose clamps, and the water box strap
06:48 Remove the Muffler pipe from the water box and out of the ski
06:51 Note about removing intercooler
06:58 A look at the stock belt tensioner assy.
07:31 Releasing tension from the spring to remove the belt
08:12 Taking a closer look at the old belt
08:30 Removing engine mount bolts (14mm)
09:55 Using a 2x6 piece of wood to move engine forward
10:07 Slide the engine forward on the mounts
10:20 Slip old belt off
10:30 Comparing the new belt to the old belt
11:14 Slip new belt on, Slide engine back, reconnect coupler, tighten engine mount bolts
12:30 Torque engine mounts
12:44 Conclusion
