How to Upload Cisco Nexus Titanium Switch in GNS3

Описание: Cisco Nexus Titanium Switch Image Download Link:
https://drive.google.com/file/d/1lIzc...

---------------------------------CLI------------------------------------

Assign static IP in router 01

#Config t
#interface fastethernet 0/0
#ip address 192.168.0.1 255.255.255.0
#no shut
#end
#wr

---------------------------------------------------------------
Assign static IP in router 02

#Config t
#interface fastethernet 0/0
#ip address 192.168.10.1 255.255.255.0
#no shut
#end
#wr

---------------------------------------------------
Assign static IP Cisco Nexus Titanium

interface ethernet 2/1

#Config t
#interface ethernet 2/1
#ip address 192.168.0.2 255.255.255.0
#no shut

--------------------------------------------
interface ethernet 2/2

#interface ethernet 2/2
#ip address 192.168.10.2 255.255.255.0
#no shut
#copy running-config startup-config

----------------------------------------
Configure Static Route:

Router 01 :
ip route 192.168.10.0 255.255.255.0 192.168.0.2

router 02:
ip route 192.168.0.0 255.255.255.0 192.168.10.2



------------------------------------------------------------------
