G83 Deep hole Drilling cycle|

Описание: #CNC #vmcprogramming

#g83 Peck Drilling Cycle (Deep Hole) for Fanuc

G83 Peck Drilling Cycle G-code is modal so that it is activated every X and/or Y axis move, and it will rapid to that position and then cause this canned cycle (Drilling) to be executed again, until it's canceled (G80).

Contents

G83 Deep Hole Peck Drilling Cycle Operation

G83 Peck Drilling Cycle Format

G83 Deep Hole Peck Drilling Cycle Operation



#G83 Deep Hole Peck Drilling Cycle for Fanuc

As G83 is a Peck drilling cycle so the depth for each peck in G83 drilling cycle will be the amount defined with Q.

The tool will take the peck (Q deep)
Then the tool will rapid up to the R plane after each peck
and then back in for the next peck
until Z depth is reached.

Use G98 and G99 for the Z position clearance location for positioning between holes.

G83 Peck Drilling Cycle Format

G83 X_ Y_ Z_ R_ Q_ F_ K_ ;

X Y – Hole position data
Z – Z-depth (feed to Z-depth starting from R plane)
R – Position of the R plane
Q – Depth of cut for each cutting feed (depth of each peck)
F – Cutting feedrate
K – Number of repeats (if required)
