65% Keyboard Case Design
Автор: Quantrik
Загружено: 2018-08-22
Просмотров: 49684
Описание:
Hi All,
This a video about how I design a 65% keyboard from start to end using Fusion 360.
00:00:00 Intro
00:19:36 Plate Layout Generation
00:23:27 Fixing Generated Plate
00:32:53 Making Case Top
00:42:45 Making Case Bottom
01:00:20 Rounding Case Corners
01:04:30 Side Profile Design
01:11:30 Weight Design
01:18:30 Weight Mounting
01:22:30 Case Screws
01:40:20 Plate Mounting
01:58:30 Rendering
Corrections:
00:46:00 - You actually want at least 7mm under the bottom of the plate.
Missing:
Connector hole design. (this is dependent upon PCB design which was not covered in this video)
Feel free to leave any questions in the comments!
