APC Back-UPS 1600VA BX1600MI-GR battery replacement

Описание: APC Back-UPS 1600VA BX1600MI-GR battery replacement

Update:
See the pinned comment, TL/DR:
1) Use some double sided tape to glue the new batteries together before installing them (reduces rattle and makes the next disassembly easier).
2) Use the opportunity to closely inspect cables and connectors to see if anything is loose or burnt.

How I've replaced batteries on my APC Back-UPS 1600VA BX1600MI-GR.
Offical APC battery model:
APC RBC17

Battery model I used:
WP1236W Long F2

Battery physical dimensions:
Length: 151 mm
Width: 65 mm
Height: 94 mm
Total Height (including terminals): 100 mm
Terminal Type: F2 (6.35 mm spade connectors)
Weight: Approx. 2.65 kg
Voltage: 12 V
Capacity: 9 Ah

CONTENTS:
00:00 Introduction
00:24 Pulling the battery connector out
00:58 Removing the case bolts
02:37 Prying open the front cover
03:33 Opening the case
04:00 Removing the battery
06:49 Battery properties
07:25 Checking and connecting batteries
08:40 Installing the new batteries
10:25 Closing the cover
12:06 Checking if it works
