AXYZ CNC Router – Model: 4010. Year 2019 with ATC
Автор: Jim Unsworth
Загружено: 2020-11-29
Просмотров: 6842
Описание:
AXYZ CNC Router – Model: 4010. (4' x 10' process area), Year 2019,
Mint condition, * less than 100 hours usage.
Can handle 50 inches wide sheets.
7 tool Auto Tool Changer,
ISM Tangential Knife for vinyl cutting.
Voltage 208 – 240, 3 Phase. 27.8 Amps. 50/60 Hz
SERVO Motors on All Axis.
Latest A2MC Controller
12 HP, HSD variable to 24,000 RPM.
Plumbed Vacuum table all you need is a vacuum pump. I didn't need one as was cutting very small parts. In touch with refurbished Becker or Busch for $5,000.
Any tooling I have for the machine is included. 7 Collets up to 3/4 inch shafts.
Requires compressed air - 60-80 gal is about right. Compressor extra.
Under power for inspection.
Footprint:
12 ½ feet x 104 inches
Gantry Width: 104 inches
Table Length: 12 ½ feet
Table Height: 6 feet from floor to top of Spindle.
Bottom Gantry to table: 7 inches
Maximum Panel Width 50 inches
Process cutting Area: 4 x 10 feet
Location: St. Catherines, Ontario - Call Jim - 905 745 6663
