Microstripline to Waveguide Transition (MWT) for Radar System in HFSS
Автор: TechSim Lab
Загружено: 2022-08-18
Просмотров: 2843
Описание: In this video we are going to design microstripline to waveguide transition for radar system. Step to design Microstripline to waveguide transition (MWT) for Radar system Radar system Application requirements: 1. Operational Frequency (65 GHz) 2. Bandwidth 60 to 70 GHz Step 1. Select the waveguide for the required spectrum Eband = WR12 = dimensions (3.1mmx1.55mm) Step 2. find the low loss substrate for high frequencies RF35A2 is my choice for mm-wave applications Step 3. Analyze microstrip and waveguide separately before designing the transition CST, HFSS, Tips and tricks hfss and cst, Antenna, Waveguide, microstrip, Microstrip to waveguide transition, Radar system,millimeter wave radar, Eband, Waveguide transition design, Microstripline transition design
