No.57 V-A(0-5V to 4-20mA) Signal Converter at 250 Ohm Load
Автор: 멀티심 MultiSim 전자회로 시뮬레이션 모음
Загружено: 2024-03-17
Просмотров: 128
Описание:
If we are working in the electronics field, you will come across a wide variety of cases in which circuit design with the same purpose is approached differently depending on each person's ideology and experience. I think this is because various variables are taken into consideration, such as precision of performance depending on the configuration, availability, cost of parts, convenience in power supply, and ease of connection to peripheral circuits.
The circuit presented this time is recommended in terms of linearity.
But, as you can see in the video, the response at 'pulse' 1Hz repeats stabilization and shaking, and the stability is not very good.
Let us encourage you to evaluate it together through simulation.
BGM : Piano-Concerto-no21-in-C-major-K467-II-Andante / Helmut Alsdorf
#MultiSim #Simulation #Circuits #Electronics
