**Description**

In this project, when Arduino initializes and starts executing the code. A 12V air compressor inflates the wheel, while an HX 710B air pressure sensor continuously measures the wheel’s pressure and displays it on a 16x2 LCD. If the pressure becomes low, the LCD shows a "Pressure Low" message, and the GSM module sends an SMS alert to notify the person of the issue. More features can also be added in this project.

**Working**

When the battery is turned on, it supplies power to the entire circuit. The 7805-voltage regulator then provides a stable 5V output for the Arduino and other components. Once the Arduino initializes, it begins executing its code. Meanwhile, a 12V air compressor starts filling air in the wheel. The HX 710B air pressure sensor continuously monitors the pressure inside the wheel and displays the current air pressure readings on a 16x2 LCD screen. If the sensor detects that the pressure inside the wheel becomes low, the LCD displays a "Pressure Low" message. Simultaneously, the GSM module is activated and sends an SMS alert to the person, notifying them of the low-pressure condition. This system ensures real-time monitoring and immediate notification for effective maintenance.

**Components required**

Arduino (Microcontroller)
12V air compressor
HX 710B air pressure sensor
16X2 LCD
GSM
Wheel
5V regulator
Battery
Connecting wires
Objectives
Pressure Measurement

To continuously measure and display the air pressure inside the wheel using the HX 710B air pressure sensor.
Low Pressure Detection
To detect when the pressure falls low and trigger an alert to indicate low pressure.
Instant Alert System
To activate a GSM module which sends a SMS notification to the person when low pressure is detected.
Inflation Control
To use a 12V air compressor which automatically fill the wheel when pressure is low.
