FreeCAD Tutorial for beginners, 3D Exercise_
Автор: CADCAM - ZFE
Загружено: 2026-02-26
Просмотров: 124
Описание:
In this quick and informative tutorial, I will show you, how to create a 3D Model from existing 2D drawing, with the help of FreeCAD part design tools, like Extrude, Cylinder, Hole, Thread, Chamfer, and Fillet.
-----------------
֍TIMESTAMPS֎
00:00 -- Intro:
00:30 -- Steps,& the tools, that I used in this exercise
01:04 – Create main part (pos.1) / Extrude & Draft tools.
02:43 – Removing material (pos.2) / Pocket, Polar Pattern and Fillet tools.
06:50 – Removing material (pos.3) / Pocket, Draft and Fillet tools.
07:50 – Give thickness to the solid part(pos.4) / Thicknes tool.
08:18 -- Close
------------------
