PNMF series Plastic Pulverizer blade,Pulverizer grinding disc manufacturer from WANROOETECH

Описание: China WANROOETECH design,manufacture PNMF series Plastic Pulverizer blade,Pulverizer grinding disc, and also make plastic pulverizer,PVC pulverizer machine,PE pulverizer machine etc. Our factory can supply the high quality, competitive price. If you want to know much more info, please visit our website:
http://www.wanrooe.com/
email: [email protected]

WANROOETECH PNMF-HIGH SPEED PRECISION PULVERIZER
Advantages of the PNMF Pulverizers
Simple adjustment of cutting gap
Choice of discs or segments
Low drive power
High throughput
Innovative efficient design
Wide range of accessories
Easy temperature control
PNMF Pulverizer Configuration
The WANROOETECH PNMF Pulverizers can be equipped with either one piece or segmented grinding discs; both are made from high quality tool steel and can be treated to withstand wear longer.
The material temperature is monitored in the process; an automated cooling system will ensure the temperature is kept at a defined level.

The material is fed into the Pulverizer by a vibrating dosing channel; the feeding rate is automatically adjusted based on the motors amperage and material temperature.
PNMF Series Pulverizer General Description
The disc pulverizers of the PNMF series are available with disc diameter from 300 to 800 mm.These pulverizers are high speed, precision grinders for the processing of medium hard, impact resistant and friable materials. The material to be pulverized is introduced through the centre of a vertically fixed grinding disc which is mounted concentrically with an identical high speed rotating disc. Centrifugal force carries the material through the grinding area and the resulting powder is collected with a blower and cyclone system. Depending on the application the machines can be equipped with one piece grinding discs or grinding segments.
PNMF Series Pulverizer Applications
One of the main fields of use for the WANROOETECH PNMF Pulverizers is the pulverization of PVC regrind in pipe and profile recycling. Working in line with a shredder and granulator to have a balanced and efficient system to handle in house production waste. Another application is the grinding of PE for Rotomolding applications, here the PNMF Pulverizer is used in the production process to create the powder needed in the process. In this process a screening machine is necessary to ensure the right output size, distribution and flow properties of the ground material.
