How to control Window Curtains with Phone: DIY Arduino Automation (2024)

Описание: This is Part 2 of the Curtain Automation. In this video, I show a step-by-step guide to control your curtain from anywhere using the Arduino IOT Cloud App via the new Arduino R4 WiFi board instead of physical buttons.

Also, if you have the paid version of the Arduino IOT Cloud, you can connect it to Amazon Alexa.

Arduino Code: https://create.arduino.cc/editor/wedg...

For more details on the rope/pulley installation, also watch Part 1:    • How to automate any Window Curtain for $20...

Visit the Arduino Project Hub for all details of Part 1: https://projecthub.arduino.cc/wedgeha...

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Got something you want to see the Wedge Hacker automate? Great! Just drop your idea in the comments section ( I read all comments, literally).

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The window curtain is automated using Arduino R4 WiFi and a NEMA-17 Stepper Motor. Keep in mind, that you'll need an ordinary Curtain that uses a rail and a rope for opening and closing*.



Arduino Code:

Components Required:
NEMA-17 Stepper Motor: https://s.click.aliexpress.com/e/_DDS...
Pulley Belt: https://s.click.aliexpress.com/e/_DlV...
L298N Dual H-Bridge Motor Driver (Compatible): https://s.click.aliexpress.com/e/_Dnt...
Single Relay: https://s.click.aliexpress.com/e/_Dmn...
Arduino UNO R4 WiFi (Genuine): https://store-usa.arduino.cc/products...
12v Power Adapter: https://s.click.aliexpress.com/e/_DkC...
Female-to-Female Jumpers
Male-to-Male Jumpers
6mm Wall Plugs and Screws
