MOD 12 Hour Clock using 4026 IC Simulation Circuit By INVENTIVE TECHNICAL SUPPORT

Описание: I have made a project which is MOD 12 Hour Clock using Six 4026 IC , 555 timer IC and Six 7 segment display (Common Cathod).This Circuit Works as 12 Hour Clock Simulation. In the next video I'll made 00 to 59 Counter , 00 to 11 Counter, 00 to 23 Counter, Pure 1hz Clock Friquency.
If you like to see my video then Please SUBSCRIBE to my channel, Comment for more information about Electronics Project.

This circuit can be easily made at home. You can made it too. It take some component to make it which I used.

1. Six 7 Segment Display
2. Six 4026 IC
3. 555 Timer IC
4. 330 Ohm Resistor
5. 1 K Resistor
6. 10 K Resistor
5. 1N 4007 Diod
6. 25V 100uF Capacitor
7. BC 547 Transistor
8. Push Button
9. Red LED (5 mm)

this is Software Based Circuit Simulation, In the Next I'll Upload Bradeboard Circuit part by part.

Please SUBSCRIBE to my Channel (INVENTIVE TECHNICAL SUPPORT)
and follow me into my social accounts given bilow.
Thanks for watching this Video.
