Doosan Puma MX-2100ST CNC Multi Axis Turning Milling 5 Axis Machine - MachineStation

Описание: Please Call us at 909-919-9600 or Visit us at http://www.MachineStation.us for more details., MachineStation, 4520 Danito Court, Chino, CA 91710

https://www.machinestation.us/product...

Make: Doosan
Model No.: MX-2100ST
Serial No.:
YEAR: 2008
Condition: Very Good

Comes with 8″ Chucks, Tool Holders, Chip Conveyor & Manuals
All specifications are approximations, and are subject to verification.

“One Our Floor, Fully powered / tested & in Great working condition. One owner, Original paint machine, Equipped with 2 Chucks, Full C Axis, Milling, Sub Spindle, Second Turret and Y Axis. Comes with Chip conveyor, Manuals.”
——————————————————-
Doosan MX-2100ST Equipped With:

Fanuc 31iA CNC Control
12000 RPM Pendulum Milling Head
Powerful (22kw) 30 HP high-torque integral spindle motors
High speed 5,000 RPM spindles
Servo driven 40 station ATC with 1.8 sec tool to tool time
Servo Controlled Full C-Axis on Both Spindles
12 Station lower turret with Live tool capability
Y Axis Capability
PCMCIA Card Slot
Tool monitoring system – wear and breakage detection
Automated Parts Unloading system
8″ Big Bore Chuck on Main Spindle
8″ Chuck on Sub Spindle
Rigid Tapping on Both Spindles
Foot Operated Control for Chuck
High Pressure Coolant System
Chip Conveyor
Inbuilt Transformer
Chiller Unit
Comes with Tools, Chip Conveyor, Books & Manuals.

Doosan MX-2100ST Specifications:

Capacity:
Max Turning Diameter Upper Turret : 21.25″
Max Turning Diameter Lower Turret : 11.89″
Max Swing Upper Turret : 29.5″
Max Swing with Y Axis : 19.70″
Max Swing over Cross Slide : 23.6″
Max Turning Length: 40.15″
Max Bar Capacity Main Spindle : 2.625″
Max Bar Capacity Sub Spindle : 2.55″
Max Weight on Main & Sub Spindle : 1322 lbs
Max Distance Between Main & Sub Spindle: 52.50″

Travels:
X1 Axis Travel Upper : 22.24″
X2 Axis Travel Lower : 7.36″
Z1 Axis Travel Upper : 41.3″
Z2 Axis Travel Lower : 41.3″
Y Axis Travel: 6.7″
W Axis Travel: 41.34″ ( Sub Spindle )
C Axis: 360° (0.001°) Both Spindle
B Axis Travel: 240°

Feedrate:
Rapid Traverse X Axis: 1417 IPM
Rapid Traverse Z Axis: 1417 IPM
Rapid Traverse Y Axis: 1351 IPM
Rapid Traverse B Axis: 1181 IPM

Spindle:
Main Spindle Bore: 2.99″
Sub Spindle Bore: 2.99″
Main Spindle Nose: A2-6
Sub Spindle Nose: A2-6
Main Spindle Speed: 35-5000 RPM
Sub Spindle Speed: 35-5000 RPM
Main Spindle Power: 22 kw
Sub Spindle Power: 22 kw

Milling Head:
Single Station Pendulum Head with 40 ATC
Tool Type: CAPTO-C6, 40 Taper
Spindle Speed: 15-12000 RPM
Spindle Motor: 18.5 kw
Spindle 5° Index Time: 0.5 Sec

Lower Turret:
Capacity: 12 Live Stations
Tool Holder Type: BMT-55P
Turret Index Time: 0.2Second
OD Tool Size: 1.00″
ID Tool Size : 1.50″
Live Tool Speed: 5000 RPM

General:
Power: 87 kva, 220v / 3-Phase
Air Required: 71 PSI
Overall Dimensions: 192″ x 99″ x 110″ High
Overall Dimensions: 210″ x 99″ x 110″ High with Chip Conveyor
Weight: 26,500 lbs

Doosan MX-2100ST Comes as shown in pictures..
