Inglet Inblade Pro Vertical Cutter Operation Video

Описание: The InBlade Pro adds the comfort to the already unique features of the InBlade thanks to the power of the pneumatic cylinder that moves quickly and accurately the cutting head. The pneumatic cylinder combined with the reliable linear bearing system to guide the cutting head allows the cutting of any material with no need of downward hand pressure.

The InBlade Pro is equipped also with a speed control to regulate the velocity of the cutting head depending on the material to be cut, required to guarantee a smooth cut for all uses. The interchangeable cutting head system offers an easy-to-use solution to hold all the available cutting heads and it is ready for being used by new tools developed in the future.

The InBlade Pro cutter is available in four cutting sizes: 165 cm (65”), 210 cm (82”), 250 cm (98”) & 305 cm (120") and it allows cutting the surprising maximum thickness of 20 mm.

Materials that the Inblade Pro cuts: Acrylic / Plexiglas®, aluminum sheets, aluminum composites / Dibond®, MDF, glass, foamboard, PVC, cardboard, honeycomb / Re-board®, corrugated plastic, mountboard…

Includes:
• Cutting head for aluminium composites (up to 4 mm).
• Cutting head for semi-rigid materials (up to 13 mm).

Why is it different?
▸ Easy interchangeable cutting head system:
Interchangeable cutting head system and double handle system for cutting comfortably tough and rigid materials.

▸ Accurate cutting head movement:
Two bearing blocks located on a linear rail for a fast and accurate cutting head movement.

▸ Pneumatic clamping:
The pneumatic clamping system offers an easy, fast and reliable way to hold the material.

▸ Up to 20 mm:
Cutting thickness up to 20 mm for semi-rigid materials.

Other features:
• Guided counterbalance supports the load of the cutting head to facilitate the work.
• Telescopic legs to find easily the most comfortable working position.
• Easy to set up and to square through the adjusting screw system.
• Can be mounted on the wall or supported by a free standing accessory.
