Today we're going to be taking a look at the Replacement Control Module for an Electric Coach Step. This replaces the control module that came standard on your single, double, or triple electric Lippert Coach Step, or Stromberg Carlson Sliding Step. This unit simply houses the circuits and electrical components necessary for the step to function properly. It's going to include the weatherproof wiring and connectors. It installs underneath the base of your step with four self-tapping screws. The screws are not included, but when you're ready to install this, you'll remove the self-tapping screws holding the ground wires on your previous module. Then you'll need to disconnect the four pin connector to the motor wiring harness, that will look just like this one.

Disconnect the two pin connector to the motor, it's going to look just like this one. Remove the self-tapping screws holding your module in place, and simply install the new module in reverse order. A few measurements to go over with you real quick and then we're going to go over a few of the wire functions. Edge to edge going this direction, it's going to give us a measurement of 5 13/16". Going this direction, just measuring the box portion, that's going to be 4 1/8". The holes are separated on center going this direction by 3 1/8", and the hole separation on center in this direction, is going to be 5.25". Really nice design.

Again, you're going to have your four pin connector, goes to the motor wiring harness. Two pin connector that goes directly to the motor and then your black wire right here, this is going to be the wire that gets connected for the step light. You're going to have two green wires, these are both ground wires. One grounds the chassis, the other one grounds to the steps. Then your purple wire, located right here, this is going to be for the step light switch.

That's going to do it for today's look at the Replacement Control Module for an Electric Coach Step. Again, this replaces the control module that came standard on your single, double, or triple electric Lippert Coach Step or Stromberg Carlson Sliding Step.
