Pneumatico Lift - Rail Track System For Tool Balancers

Описание: [email protected] | (978) 560-3775 | toolbalancersusa.com | Welcome to toolbalancersusa.com! In this video, we introduce the PNEUMATICO LIFT rail system designed for ergonomic workstation organization. This innovative system provides a simple and secure suspension and movement solution for pneumatic tools and power tools, ensuring optimal workflow and enhanced versatility in various work environments.

The video begins by showcasing the key elements of the rail track system. A rail is positioned on top, and a trolley is suspended from it, demonstrating an example setup with a nail gun equipped with a balancer and an air hose. Adjacent to it, another trolley supports an air hose connected to the compressed air installation. This configuration allows for confident maneuvering of the nail gun, ensuring it remains securely in place when released.

The rail system consists of robust galvanized rails with a 40mm by 40mm profile and a wall thickness of 2.5mm. These rails come in lengths of 200cm (6.5 feet) and are designed to accommodate the various components of the system. Each rail requires a trolley, and the video showcases the tool suspension trolley featuring a suspension hole, four durable steel wheels with bearings, and rubber bumpers at the ends to prevent noise and wear.

To limit the movement of individual trolleys, end stops are introduced. These end stops can be easily installed by screwing them into the rail, offering flexibility and allowing multiple trolleys to be accommodated on a single rail. The video also presents a smaller trolley with two wheels, ideal for suspending special air hoses, electrical cords, and coil hoses. Rail caps are available to cover any sharp edges, providing a polished look and added safety.

Different mounting options for the rail system are discussed. The video showcases a robust and secure rail mount that can be fixed to the ceiling or other surfaces using screws. Another mounting option requires the use of two screws for secure attachment. Additionally, wall-mounted installations are presented as a convenient and space-saving alternative.

For seamless extension of the rail system, couplers are introduced. These connectors allow for the extension of the rail system throughout the entire workspace by securely fastening rails together using top and side screws. The video highlights the H system module, which enables movement of tools in two axes, enhancing versatility and adaptability.

Practical examples are demonstrated to showcase the functionality of the rail system. One example features a complete system with a balancer, rail, trolley, tool balancer with a load, end stops, and rail caps, ensuring a smooth workflow. Another example demonstrates the suspension of a nail gun on a tool balancer with an air hose, utilizing four-wheel and two-wheel trolleys, end stops, and caps for seamless movement.

The video concludes by highlighting the common use of this rail system in pallet production. A Bostitch nail gun with a special hook hanger is showcased, allowing easy attachment to a tool balancer. The balancer is equipped with a coil air hose, and an additional trolley suspends another coil hose. This setup enables convenient and smooth work, with the ability to release the nailer at any time without issues.

Discover the benefits of the rail track system, its versatility, and ergonomic advantages by watching this informative video. Upgrade your workstation organization and enhance productivity with the PNEUMATICO LIFT rail system from toolbalancersusa.com.
