These Are The Easiest Ways To Draw Keyholes, and Many Other Shapes in CATIA V5 Sketcher - Tutorial 5
Автор: Bogdan Zamfir
Загружено: 2021-09-13
Просмотров: 49
Описание:
In this tutorial I show you how you can easily draw the shapes under the rectangle command, using two methods.
The shapes I am talking about are the oriented rectangle, the parallelogram, the elongated hole, the cylindrical elongated hole, the keyhole, the hexagon, the centered rectangle, and the centered parallelogram.
The first method is by drawing each shape using coordinates, lengths, and angles which must be introduced in the required fields.
The second method is by simply drawing each shape in the working area and after that by using the constraints command, dimension your shape as you desire. Enjoy!
Thanks for watching!
If you find my content valuable, please like the video and subscribe to the channel!
Thank you very much and I wish you all the best!
Bogdan
