Mitsubishi Heavy industries 1 Ton inverter AC Unboxing | Made in Thailand | R32 Gas Model DXK12ZSA-W

Описание: Mitsubishi Heavy industries 1 Ton inverter AC with R32 Refrigerant Unboxing By Rehan Arshad Channel Model indoor DXK12ZSA-W and Outdoor DXC12ZSA-W Made in Thailand Australia Model Detailed Review

Extra High Premium Quality Export Only

#mitsubishi HEAVY INDUSTRIES AVANTI 3.5KW (C) / 3.7KW (H)
Indoor Unit DXK12ZSA-W
Outdoor Unit DXC12ZSA-W
Power Supply 1 phase, 240V, 50Hz
Rated Capacity Cool (kW) 3.5
Heat (kW) 3.7
Capacity Range Cool (kW) 0.9-4.4
Heat (kW) 0.9-5.4
Power Consumption Cool (kW) 0.82 (0.18-1.27)
Heat (kW) 0.81 (0.21-1.44)
Max Power Consumption (kW) 1.65
Running Current Cooling (A) 3.7
Heating (A) 3.7
Inrush Current, Max Current (A) 3.9, 9.0
EER Cooling 4.27
COP Heating 4.57
Outdoor Pressure Level (dBA) 50

Dimensions (HxWxD) Indoor (mm) 290x870x230
Outdoor (mm) 540×780(+62)x290
Weight Indoor (kg) 10
Outdoor (kg) 36
Indoor Airflow Rate (H) Cool (l/s) 205-152-117-78
Heat (l/s) 250-193-117-88
Refrigerant Type Type/Amount (kg) R32/0.75
Pre-Charged Length (m) 15
Pipe Sizes Liquid (mm) 6.35
Gas (mm) 9.52
Connection Method Flare Connection
Max Pipe Length (m) 20
Max Level Difference (m) 10
Standard Accessories Allergen Clear & Photocatalytic
Washable Deodorizing Filter
Demand Response

KEY FEATURES
It’s the unique features of Mitsubishi Heavy Industries

Clean Air Technology
Removes airborne allergens such as pollen and dust by capturing them in a specially formulated Allergen Clear Filter and neutralising them via the multi-stage Allergen Clear Operation.

Jet Air Technology
Utilising CFD (Computational Fluid Dynamics), used by jet engine manufacturers, our engineers have been able to improve and optimise the design the internal fan blades, allowing our split systems to deliver the most powerful yet efficient airflow possible.

LED Brightness Adjustment
Adjust the brightness of the LED display on the indoor unit to minimise disturbance and ensure a good nights sleep.

High Power Operation
Provides 15mins of boosted power allowing you to quickly heat or cool your home before returning to normal operation. Perfect for when you first turn on the unit.

Weekly Timer
Set up to 4 timer operations a day (max 28 per week). Once set, the unit will turn on and off at the specified times of the day repeatedly
MITSUBISHI HEAVY INDUSTRIES TECHNOLOGY

Improved Heat Exchanger
A new and improved heat exchanger has been developed to improve refrigerant distribution and increase the systems effectiveness. The new design features a larger heat exchange area, boosting the unit’s overall efficiency.
Mitsubishi Heavy Industries outdoor units are coated with specially formulated layers.

DC PAM Inverter
The PAM control used in Mitsubishi Heavy Industries air conditioners helps minimise the loss of electricity and boost the efficiency by allowing the unit to reach the temperature quickly before slowing down the compressor. This allows the unit to save energy while maintaining a comfortable temperature in the room.

Coated PCB
To protect against humid weather a protective coating is applied to the circuit board in the outdoor unit, allowing it to withstand Australia’s varying weather conditions and ensure the longevity of your system.
High Efficiency Compressor
One of the key features that provides Mitsubishi Heavy Industries air conditioners with their powerful performance is their highly efficient compressor. Combined with a Neodymium motor that uses powerful, rare earth magnets, Mitsubishi Heavy Industries air conditioners can deliver a higher motor efficiency while producing much less operational noise.

Wide Operation Range
With their advanced technology and high quality components, Mitsubishi Heavy Industries air conditioners can operate in ambient outdoor temperatures as low as -20˚C in heating mode and as high as +50˚C in cooling mode. This permits the installation in areas where the temperature conditions can be considered extreme.

#MITSUBISHI HEAVY INDUSTRIES AVANTI
Residential #airconditioner

Wireless Remote Controller

• Mode button to select from Cool, Heat, Dry, Auto or Fan Only
• Hi Power mode to run the unit in a boosted power mode to quickly achieve the desired room temperature.
• Allergen Clear function to neautralise and eliminate allergens caught in the filter, ensuring a clean air throughout your home.
• Airflow Direction to adjust the louvres up/down and right/left angles or activate swing mode.
• Weekly Timer to set up to 4 timer operations a day (max 28 per week). Once set, the unit will turn on and off at the specified times of the day repeatedly.
• 3D Auto Mode button to activate the three independent air flow controls allowing for an even airflow to be delivered across the entire room.
• Child Lock function to disable the controller and prevent inadvertent changes to the control settings from the youngest members of the family.
• Night Setback to maintain your room temperature during cold conditions, even when the room is
