KEAUP MECHANICAL 125: BUDGET BROADHEAD TEST

Описание: This is a test of the Keaup 125 gr mechanical 2 blade broadhead, so on Amazon for $4.33/head, in a 6 pack for $24.99.

Here is summary of my 2025 Testing Procedure & Scoring w/the scores of this head posted in parenthesis as well.

1. Flight Forgiveness (20%, 21 pts)
I'm using a Killer Instinct LogiX435 crossbow, mounted to a BOG tripod, shooting a 685 gr Bishop GOAT bolt (310 fps) @ 30 yds. Field pts consistently hit in the 10 ring & bullseye. I use the exact same bolt to shoot the broadhead. The only diff in the 2 shots is the broadhead's flight forgiveness vs that of the field pt. A bullseye gets a score of 11/10, or a score of 22. The 10 ring gets a 10/10, or 20 points; a 9 ring gets a 9/10 or 18 points...& so forth, w/ each wider ring being 1/2" farther from the bullseye. Mechs are also given 1 Bonus Point for extra forgiveness.

2. Cut Size (20%, 18.60 pts)
The more tissue being cut, the more lethal the head, all else equal. The entrance cut, total cut, & width of the cut (a crucial variable for bloodletting) are all scored:
The entrance cut size is compared to a standard of 2.5" then that fraction is weighted to 7% of the score. (2" +.25" tip =2.25" = 6.3 pts)
The max cut size is compared to a standard of 2.5" as well, then that fraction is is weighted to 7% of the score. (2.25”=6.3 pts)
The max cutting diameter is compared to a standard of 2.0", then that fraction is weighted to 6% of the score. (2" = 6 pts)

3. Blades (20%, 19.75 pts)
Initial sharpness 9%, 142 grams = 10/10=9pts +.58 pts bonus=9.58 pts & Edge Retention (9%, +31 grams = 9.74/10 = 8.77 pts) are measured using the Edge On Up Sharpness Tester. The pressure needed for a blade to cut thru a copolymer wire is measured in grams.
Edge Retention is the loss of sharpness after the head is shot in Pen Test 1, thru 1/2" MDF & 2/3" rubber foam mat & Clear Ballistics FBI gel. For every 50 "grams" of sharpness lost, 1 point is deducted from 10.

What are some sharpness scores for common edges?
A butter knife takes 2000 grams of pressure to break the co polymer wire.
A new high end cutlery edge: ~ 375 grams of pressure.
A utility razor blade: 200 grams.
Based on the many broadheads I have tested, here is my scoring scale:
Out of the Box Sharpness:
0-200 gr: 10
201-300 gr 9
301-400 gr: 8
401-500 gr: 7
501-600 gr: 6
601-700 gr: 5

Ease to resharpen or replace blades is judged & given 2% of the score. (7/10= 1.4 pts)

4. Penetration (20%, 15.64 pts)
There are 2 penetration tests:
Pen Test 1: 1/2" MDF, 2/3" rubber foam mat, Clear Ballistics FBI gel. Depth of penetration is compared to a standard of 9" & weighted to 10% of the score. (7" = 7.78 pts)
Pen Test 2: Layered cardboard. # of layers penetrated is compared to a standard of 70 layers & weighted to 10% of the score. 55 layers = 7.86 pts

5. Durability (20%, 16.1 pts)
Each head is shot thru 1/2" MDF 3 times. Its condition is judged 1-10 & weighted to 12% of the score. (9/10=10.8 pts)
If a head survives that, it is then shot thru 22 ga steel plate twice. Its condition is judged 1-10 & weighted to 5% of the score. (7/10 = 3.5 pts)
It is then shot into concrete once. Its condition is judged 1-10 & weighted to 3% of the score. (6/10=1.8 pts).
Steel plate & concrete are certainly not "realistic" mediums, but they do reveal the outer limits of a head's durability.

Bonus: +2 pts Sharpness & Edge under 200 grams
+1 pt No O rings or clips

TOTAL SCORE: 95.09 pts =10 Golden Arrows

Price: $4.33/head
