Revit Wall Closers – Create Layer Wrapping at Wall Inserts & Ends

Описание: Download Tutorial Model: https://www.buymeacoffee.com/8020BIM/...
8020BIM Community Chat Channel:   / discord
In this tutorial I breakdown How to Create Wall Material Layer Returns in Revit. This video goes through the process of creating Revit Wall Assemblies from Scratch, Explaining the Revit Layer Function Priorities, Assigning the desired Wraps to the Materials as well as Wrap conditions for the wall to follow at inserts and ends.

Further to this, the tutorial covers how to resolve layer returns at inserts that do not extend to the desired width and how Window and Door families are created to allow users to manually override the layer return values at inserted elements.

The Video Content is broken down as follows:
00:00 - Introduction to Video Content

01:04 - Step 1: Creating a Wall Assembly in Revit

12:43 - Step 2: Understanding Material Layer Function Priorities in Revit

17:37 - Applying Material Layer Wrapping and Wrap Conditions to Revit Walls

28:06 - Resolving lack of control of Layer Wrapping at inserted Doors and Windows in Revit Walls.

Click the following link to see a full written step-by-step breakdown of Revit Wall Wrapping, Assebly Creation, Layer Functions and Core Boundary priorities, Creating wrapping conditions and other sub headings listed in the video from the following Link:

https://8020bim.com/revit-layer-wrapp...

Create Block and Masonry Walls to Course Intervals in Revit:
   • Create Block and Masonry Walls to Course I...
