Do You Know How Signal Travels Through a VIA? Are You Sure? | Explained by Eric Bogatin
Автор: Robert Feranec
Загружено: 2023-05-03
Просмотров: 17241
Описание:
What is happening with signals when tracks are changing layers in PCB? Thank you very much Eric.
Links:
Ansys free version: https://www.ansys.com/academic/studen...
Ten Signal Integrity Rules of Thumb webinar: https://www.signalintegrityjournal.co...
FEDEVEL courses: https://courses.fedevel.com/
Chapters:
00:00 The board
02:02 How signal travels through a via
04:32 About setup
07:26 About ground
10:38 With GND VIAs
13:45 Current, plane, skin effect
------------------------------------------------------
