Water Reticulation Tip 09 - Calculate total water volume from system demand

Описание: There may be situations where you need to determine the total water demand of your reticulation network over a specific period. The analytical engine used for water reticulation network analysis in Civil 3D with iDAS does not provide this result directly. However, you can calculate it by recording the water depth in the storage tank at the beginning and end of the analysis, calculating the change in depth, and multiplying it by the tank’s cross-sectional area (based on its diameter) to obtain the volume of water demanded.

Timestamps:
00:30 Swap reservoir to tank if needed
01:02 Tank properties
01:26 Fire hydrants settings
01:54 Single and double house connections settings
04:38 Analysis
05:02 System unbalanced error
05:49 Graph
06:03 Volume calculation
07:17 Volume calculation for specific period
07:41 Include fire hydrant demand
