Mini table saw. My version - 200 watts (with lift).

Описание: 00:00 Demonstration: cutting 16 mm plywood
00:55 Engine and bracket
01:09 Linear bearing LM8LUU, elevator parts manufacturing
02:09 Mounting the motor and saw blade shaft
02:44 Test sawing
03:26 3D elevator scheme
03:41 Assembling the lifting screw of the elevator
04:10 Elevator test
04:36 Supports for a thin top
04:53 Making the protection of the mechanism from sawdust
05:55 Cooler installation
06:03 Right cover hinges
06:37 Parallel fence
05:59 Current test at maximum load
07:21 Finished mini saw, electronics location
07:39 Soft start scheme
07:45 Soft start demonstration
08:10 Demonstration of cutting plywood 16mm, 8mm and others
09:53 Motor heating control
09:58 Checking the protection of the mechanism from sawdust
10:31 Delete temporary temperature control
10:37 Plexiglas cutting
11:18 Installation and operation of the sliding carriage

Hand Adjusting Nuts (3D printer) -    • Видео

For thick plywood, the best saw blade option is 110/115 mm 24 teeth.

Buy parts for mini circular table saw:
Engine 48V 200W - https://ali.ski/sP1XQm
Engine 48V 200~800W - https://ali.ski/nUzC-
Power unit 24V 60~500W - https://ali.ski/noB0U
Linear bearing LM8LUU - https://ali.ski/FdcTy

Shafts 10mm, 8mm - https://ali.ski/tqhXI
XL Timing Belt (I used 90XL) Pitch 5.08 mm, width 10 mm - https://ali.ski/mbvqo
Timing Pulley 10T XL (bore 8mm, width 11mm) - https://ali.ski/9YO1As
Timing Pulley 20T XL (bore 10mm, width 11mm) - https://ali.ski/14KlP
Bearings 10 mm with bracket - https://ali.ski/5fyLxs
Table Saw Drill Power Spindle - https://ali.ski/kEbFD

Thermistor NTC 5D-20 - https://ali.ski/lUrs8y
Relays SRD - https://ali.ski/z3iF9

Circular saw blades 85/110/125 mm - https://ali.ski/RADIQ
Sealing gaskets for 16 mm - https://ali.ski/68d559
Saw blade for plastic 100 x 16 mm - https://ali.ski/YFhESB
