How to Program Taper Angle Control in IGEMS for WARDJet's APEX 60 5-Axis Waterjet (Updated Jan14/22)
Автор: WARDJet - Waterjet Cutting Machines
Загружено: 2022-01-14
Просмотров: 445
Описание:
The Taper Angle Control (TAC) feature of IGEMS can be used in conjunction with our APEX 60 5-axis head to help reduce the amount of taper on a part. Taper is an inherent characteristic of the waterjet process. The faster you cut, the more taper there will be; the slower you cut, the straighter the edge will be. If you know the amount of taper at various speeds, the IGEMS software can tilt the 5-axis head slightly to adjust for this taper angle.
This video covers:
Verifying machine settings
Setting first-pass Taper Angle Control numbers in a material
Adjusting TAC numbers to further fine-tune taper
Applying TAC to 3D-5X parts
Removing TAC from a toolpath, 2D, and 3D-5X (UPDATED JAN 14, 2022)
TAC is not applied to Open Contours (UPDATED JAN 14, 2022)
Visit https://wardjet.com/products/waterjet... for more information.
