Chimera 7 LR 32' minutes, 27 Km, DJI FPV, long range flight around the city, using 60% battery !

Описание: Raw footage of a city tour with the 10.000mah 6s2p samsung 21700-50g2 li-ion cells battery.
As per title, after 27km and 32 minutes, I had consumed less than 6.000 mah on a total of 10.000 available, with the battery voltage above 20volts during load when i landed. I could have easily flight for another 15 minutes and land safely.

Video feed is from the DJI Air unit, i didn't carry the Gopro in this mission because I had the low amp / high capacity 10.000 mah lion battery, where I try not to go over 20 amps of current draw, and in this scenario I couldn't afford 200 grams of extra weight for the gopro and its mount.

The video overlay was made using Dashware, joining the logs from the goggles and the opentx telemetry. Credits to Drone racing Hungary:
( https://droneracehungary.hu/dji-srt-t... ) and Snappy FPV (    • Tutorial: OpenTX Logs in Dashware | Teleme...  ) for their tools.
See my tutorial video on how to make this overlay :    • Dahsware - How to integrate DJI SRT &  Tel...


Antennas used on goggles :
2x prodrone.pl helical 12 turn 14 db ( https://shop.prodrone.pl/pl/p/PRO-Hel... )
Truerc 5.8ghz Sniper II 13.5 DBi ( https://www.truerc.ca/shop/5-8ghz-2/r... )
VAS Cannon Helical 16T LHCP ( https://www.videoaerialsystems.com/pr... )


Images of my gear (goggles, drone, radio) : https://onedrive.live.com/?id=4E7DDD4...

Drone : Chimera 7 LR ( https://shop.iflight-rc.com/index.php... )


Weight all-out in this test was 1.400 grams.


Motors : 4x T-motor F90 1.300kv long range ( https://www.banggood.com/T-MOTOR-F90-...)


Props : Gemfan flash 7040x3 ( https://it.banggood.com/2-Pairs-Gemfa... ).


ESC : Rush Blade Super 60A 96Hz ( https://it.aliexpress.com/item/100500... )
FC : Mamba F722S blutooth ( https://www.diatone.us/products/mamba... )


Battery : 6s Li-On 6s2p 10.000Mah, 21700 Samsung INR-50G cells ( https://www.farinsframes.com/6s-10000... )



BN-220 GPS ( https://it.banggood.com/Beitian-Dual-... ).


Radio : Radiomaster TX16S ( https://it.banggood.com/RadioMaster-T... )


JR Module : TBS Crossfire TX lite ( https://www.team-blacksheep.com/produ... set to 2W


Radio antenna : TBS shapeshifter ( https://www.team-blacksheep.com/produ... ) , set in vertical position and in directional mode.


Receiver : TBS crossfire diversity nano rx ( https://www.team-blacksheep.com/produ... ) set at 8CH. Dynamic power set to off, because i want it to always work at the output power that i select in the radio.


RC Link antennas : 2 x Truerc planar bazooka dipole 868mhz antennas vertically placed, one at the front and one at the back ( https://www.truerc.ca/shop/linear-ant... ) set at 20 degrees
Video antennas : 2x tbs triumph pro (long range) ( https://www.team-blacksheep.com/produ... ).


Dji unit settings : 1.200mw, 50 mbit, High Quality, 4/3 screen, autofocus off, power control on

Betaflight main settings : 4.2.9 firmware
ESC settings : PWM 96 Hz, timings 23
