Fiber Strength Tester

Описание: Fibre Strength Tester is used to determine the tensile strength and elongation of Single Fibre, cotton, wool, ramie, silk, glass fiber, fine metallic thread, etc.

Pneumatic Fibre Grip, variable speed geared motor and Extremely powerful interactive pc software gives graphical analysis to make the machine versatile.

Elongation at specific load and load at specific elongation through the graphical analysis.


Features of Fibre Strength Tester :

Tensile strength and elongation of Fibre can be effectively determined.
Force rating up to 999.9 gm with 0.1 gm accuracy, 99.99 gm with 0.01 gm accuracy.
Cross head speed is 20 to 400 mm per minute variable.


Specifications of Fibre Strength Tester :

Force Rating: 999.9 gm with 0.1 gm accuracy, 99.99 gm with 0.01 gm accuracy

Force Resolution: 0.1 gm and 0.01 gm

Force measurement accuracy: ±0.5% of FSD

Minimum Cross head stroke: 200 mm approx

Cross head Resolution: 1 mm

Grips: Pneumatic Fibre Grip

Cross head speeds: 20 to 400 mm per minute variable.

Power Supply: 230 V AC, 50 Hz, Single Phase

Size & Weight: 40 x 44 x 20 cm, 13 Kg


Standards: BS EN ISO 13934, Parts 1&2 ASTM D-5034:1995, ASTM D-5035:1995


Fibre Strength Tester comes with calibration - warranty certificates and confirms with the international standards. For the long term customer relationship we provide these help, which is our main objective.


Minimum 10 years part availability assurance from the date of Invoice.
