Upgrading A Dewalt Table Saw To Accept A Dado Blade Set

Описание: I've been making do with a Dewalt 10" table saw for quite some time. It's been reliable and accurate, but I have always had one complaint: I cannot use a dado stack.
The Dewalt model 7480 instruction manual states that the saw cannot mount dado or stacked blades. The reason for this is the short length of the arbor. There isn't enough thread to mount much more than a single blade safely.
While perusing YouTube a while back, I found an interesting video about replacing the original arbor with a longer one. I looked into it more and thought it looked promising.
I decided to go for it and document the procedure.
Here is how it went when I decided to give it a try!

Here's the original video I used as inspiration:
   • How to Modify DeWalt DW745 and DWE7480 to ...

Link to the gasket STL file - https://github.com/MaineJason/Dewalt-...

TOOLS:
Klein Tools Metric Hex Key Set - https://amzn.to/3zLfVwJ (Amazon)*
Wiha 12-Piece Slotted and Phillips Screwdriver Set - https://amzn.to/3RpcdhN (Amazon)*
Stanley "Tylon" Metric Tape Measure - https://amzn.to/4hVOG2J (Amazon)*
28 Piece Transfer Punch Set - https://amzn.to/4h91O4g (Amazon)*
Dykem Layout Fluid, Blue - https://amzn.to/41GqzjW (Amazon)*
TEKTON 3/8 Inch Drive Deep 6-Point Socket Set - https://amzn.to/4j8Xxiz (Amazon)*
Yost 5.5" Vise 855-D2 - https://amzn.to/3EO8Eip (Amazon)*
Orion Bearing Puller Set - https://amzn.to/3Y6hAGk (Amazon)*
Channellock RT-3 Convertible Retaining Ring Plier Set - https://amzn.to/427cKtT 9Amazon)*
3-Jaw Gear Puller - https://amzn.to/43BNz57 9 Amazon)*
Magnetic Digital Level and Angle Finder - https://amzn.to/4iLWp4H (Amazon)*
US Stock M3-M16 Electric Tapping Machine - https://amzn.to/4bdZUxP (Amazon)*

PARTS:
DEWALT OEM 5140134-94 Table Saw Spindle - https://amzn.to/444Ex0u (Amazon)*
Small Bearing 6001NSE: #5140117-80 Table Saw Bearing - https://amzn.to/4j6zdOn (Amazon)*
Large Bearing 6003NSE: DEWALT OEM 5140117-79 - https://amzn.to/3RuTNMw (Amazon)*
OEM 5140131-58 Replacement Blade Nut - https://amzn.to/420VdEZ (Amazon)*
5140134-95 Table Saw Key - https://amzn.to/3DZIUzg (Amazon)*

FOXBC 8" Carbide Stacking Dado Blade Set - https://amzn.to/41PioBR (Amazon)*
TonGass Dado Throat Plate - https://amzn.to/43vvUvR (Amazon)*


MUSIC:
Pretty Little Petals - By Leimoti
Mozart: Piano Concerto No. 23 in A major, K. 488: I. Allegro - By Mira Ma, Eric Jacobsen, Odyssey Orchestra
Music from Epidemic Sound - 30 Day Free Trial
(https://share.epidemicsound.com/fnsd2b)

**As an Amazon Associate, I earn from qualifying purchases. There is absolutely no cost to you.*

TIMESTAMPS:
00:00 Introduction
01:19 Caution
01:36 Removing The Motor
03:35 On The Bench
03:58 DIYing A Puller
04:33 Pulling The Arbor Assembly
05:07 The Guts
05:18 Some Strategy
06:01 Pulling The Top Bearing And Drive Gear
07:22 Don't Lose This!
07:27 Bearing One Assessment
07:37 Snap Ring One Removal
07:46 Snap Ring Two Removal - If You Need To...
07:57 Pulling The Arbor Housing
08:31 Comparing The Arbors
08:43 Bearing Two Assessment
08:50 Reinstall Snap Ring Two
08:55 Installing A Frozen Arbor
09:30 Reinstall Snap Ring One
09:38 Reinstall The Key
09:48 Reinstall The Drive Gear
10:06 Reinstall Bearing One
10:29 Grease It Up!
11:08 Reinstall The Arbor Assembly
12:04 Reinstall The Motor
13:36 Reinstall The Switch
14:41 Problem One
14:58 Fusion To The Rescue
16:32 Gasket One
17:21 Problem Two
17:46 Gasket Two
17:56 True It Up!
18:30 Test It Out
19:45 Wrap Up
