Mitsubishi PLC GX Works2 Tutorial Up Down Counter Tagalog

Описание: The Counter is a PLC instruction that either increment (counts up) or decrements (counts down) an integer number value when prompted by the transition of a BIT from 0 to 1 (“zero” to “One”). Counter instructions come in three basic types: up counters, down counters, and up or down counters. For in the both UP and Down counters there is only 1 trigger that is needed to start the counting, but for up or down counter it is needed two triggerings, one for up and other for the down counter.

UP counters:
The up counter is an increment counter. which means it counts “up” with each off to on transitions input to its “CU” input. Whenever there is a true value entry in the CU input, the counter will turn on and the CV will display the count. This counter output must be activated whenever the current value is equal to or greater than the preset value (Q is active if the CV ≥ PV). The counter output instruction will increase by 1 each time the counted event occurs.

Down counter:
Down counter, instructions will count down or decrease by 1 each time the counted event occurs. Each time the countdown event occurs, the accumulated value decrease. Normally, the down counter is used together with the ascending counter to form an up / down counters.

===============

Topic: PLC Program
Lectured by: Md. Imran Kabir

Video Edit: Siddhartha Debnath Amrit
