Lab CDU: Seep motor command with and without CDU
Автор: Cyril Rossignol
Загружено: 2021-01-10
Просмотров: 179
Описание:
In this video, I am showing the impact of using a CDU when controlling a seep motor to move a turnout.
Supporting document with more details: https://drive.google.com/file/d/1_VRQ...
The basic CDU is made of
D = 1N4001
R = 76 Ohms (2x152 Ohms in parallel)
C = 2x1000uF – 35V in parallel
The advance CDU is a RKcdu1 from RK Education at £1.99 + shipping (Price Jan 2021)
I purchased or built all products used in this video. I do not endorse any of these products. These are just the one available to me at the time.
