2016-2022 Prius spare tire retrofit guide

Описание: OEM Spare tire retrofit guide for 2016-2022 Prius' that did not come with a spare tire.
You will need 7-8 pieces to complete the retrofit if you are aiming to use all OEM pieces/parts.

Here are the Toyota OEM part numbers:

Top cover piece : 58415-47110-C2
You don't necessarily need this top piece but it does fit better than using the original non spare top piece after adding the rest of the spare tire retrofitted pieces.

Center foam storage piece: 64993-47090

Right side foam storage piece: 64995-47040

Left side foam storage piece: 64997-47050

Plastic retainer pieces that sit in front area of left side and right side foam pieces: 51962-47020 ( 2x needed).
If you're not able to get to correct foam top cover piece (58415-47110-C2) mentioned above and you're going to re-use your original top cover piece then I do not recommend getting these plastic retainer pieces since it will inevitably rip the opening areas of the newly acquired left and right foam pieces, you can get away without using the plastic retainer pieces and just simply place your original top cover piece on top of the newly acquired foam pieces(albeit it won't fit as well).

Wheel tie down assembly screw: 51931-47010

There's a variety of spare wheels you can use as long as they are 5x100, for instance you can get away with using an OEM 3rd generation (2010-2015) Prius' spare tire that is 16" x 4" and uses a 135/80 tire, it's part number is 42611-20A50. I got all these spare tire parts from a 4th generation (2016-2022) Prius so it came with it's original and one inch larger 17" x 4" spare tire, its part number is 42611-47631 and uses a 125/70 sized tire.
