SECTION 392.22(B)(1) -NUMBER OF SINGLE CONDUCTOR CABLES RATED FOR 2000 VOLTS OR LESS THAT CAN BE PLACED IN A SINGLE CABLE TRAY.

Is it allowed to install single-conductor cables in a ladder-type cable tray with more than two layers? Also, did you know that the size or width of the ladder-type cable tray is determined not by percentage fill? Let’s watch this video to discover the answers!

Hello everyone! In our previous video, we covered the sizing of cable trays for multiconductor cables rated at 1000 volts or less, installed in ladder-type, ventilated trough, and solid bottom cable trays. In this video, we’ll focus on determining the maximum number of single conductor cables rated at 2000 volts or less installed in a single ladder or ventilated trough cable tray, as specified in Section 392.22(B). We'll also go through fill calculations to help clarify these concepts. So, let's get started!
