Discover The LATEST KATO Compact Machinery At The BIG Trade Show

Описание: KATO CL35 CTL SPECS:
Bucket Capacity 12.7 ft3
Bucket Width 5′ 8″
Operating Weight 7,804.4 lbs / 7,936.6 lbs
Transportation Weight 7,639.0 lbs / 7,771.3 lbs
Gradeability 30°
Travel Speed (High/Low) 4.2 mph / 6.2 mph
Tipping Capacity 4,916.3 lbs
Rated Capacity (35% Tip) 1720.7 lbs
Operating Capacity (50% Tip) 2458.2 lbs
Ground Pressure (Canopy/Cab) 5.62 psi / 5.71 psi
Bucket Digging Force 6,474 lbs
Model KUBOTA V2403-CR
Output Rating 62 hp / 2,700rpm
Fuel Tank Capacity 24 gallons
Battery 12V
Fuel Consumption 1.26 gal/hr
System Pressure 2,987.8 psi
Hydraulic Tank Capacity 10.6 gal
Aux. Hydraulic Flow 17 gpm

KATO HD35 Mini excavator specs:
Bucket Digging Force 7,662 lbs
Arm Digging Force 4,150 lbs
Travel Speed 3/1.7 mph
Swing Speed 9 min -1
Gradeability 300
Ground Pressure 4.35 psi
Model YANMAR 3TNV88F
Rated output 23HP
Fuel Tank Capacity 42 L
Max Torque 83.9N-m/1,320 min -1
Type Boom Offset with Hydraulic Cylinder
Swing Angle (L / R) 50° / 90°
Set Pressure 2,987
Control Valve 10 Way Multiple Control Valve + 1 Spare Circuit
Size 14″
Lift Above ground / Drop Below Ground 15″ / 18″
Size 14″
Lift Above ground / Drop Below Ground 15″ / 18″
