Rambottom Safety Valve in solidworks full tutorial with assembly and parts drawing and modeling
Автор: LOVCADD
Загружено: 2020-07-05
Просмотров: 16637
Описание:
watch to find how to Design Ram-bottom safety valve in solidworks including all Rambottom safety part design and assemble with easy to follow steps.
Rambottom safety valve Contents
0:00 - Intro rambottom safety valve.
0:23 - Body of Rambottom Safety Valve in solidworks.
18:56 - Valve seat of Rambottom Safety Valve in solidworks.
23:14 - Shackle of rambottom safety valve in solidworks.
28:33 - Washer in solidworks
29:45 - valve of rambottom safety valve in solidworks
34:52 - pivot of Rambottom Safety Valve in solidworks
39:54 - link of Rambottom Safety Valve in solidworks
42:04 - pin of Rambottom Safety Valve in solidworks
44:22 - split pin of Rambottom Safety Valve in solidworks
48:24 - Lever of Rambottom Safety Valve in solidworks
57:31 - spring in solidworks.
1:04:00 - Assembly of Rambottom Safety Valve in SolidWorks.
tutorial de solidworks
This video has all the details drawings related to rambottom saftey valve. visit our playlist for more.
Solidworks Assembly tutorials:
• assembly in soldworks
Machine vice in solidworks:
• Bench vice/ Machine Vice in solidworks ful...
Thanks for watching
