BBS of One Way And Two Way Slab l Bar bending Schedule I BBS of Slab

Описание: How To Make BBS Of One Way And Two Way Slab l Bar Bending Schedule l Practical

#BBSofslab #barbendingschedule #howtomakebbsofslab #bbsofslabinexcel
In this video,
I have explained how to calculate steel reinforcement of one way slab and two way slab on site practically
Cutting length of Main bent up Bar of Slab
Cutting length of Distribution Bar of slab

Shorter Direction Cutting Length :
Length of Main Bar ( Shorter Length ) = Left Side anchorage length + Length of Slab in Shorter Direction + 0.42 x d + Right Side Anchorage Length
where , d = depth of slab - top cover - bottom cover - half dia of main bar

No. of Main Bars in Shorter Direction = (Length of Slab in Longer Direction)/ (Spacing of Main Bars) + 1

Distribution Bars in ( Shorter Direction ) = Left Side anchorage length + Length of Slab in Shorter Direction + Right Side Anchorage Length

No. of Distribution Bars in Shorter Direction = (L/5 or L/7 Length of Slab in Longer Direction)/ (Spacing of Distribution Bars) + 1

Longer Direction Cutting Length :
Length of Main Bar ( Longer Length ) = Left Side anchorage length + Length of Slab in Longer Direction + 0.42 x d + Right Side Anchorage Length
where , d = depth of slab - top cover - bottom cover - half dia of main bar

No. of Main Bars in Longer Direction = (Length of Slab in Shorter Direction)/ (Spacing of Main Bars) + 1

Distribution Bars in ( Longer Direction ) = Left Side anchorage length + Length of Slab in Longer Direction + Right Side Anchorage Length

No. of Distribution Bars in Longer Direction = (L/5 or L/7 Length of Slab in Shorter Direction)/ (Spacing of Distribution Bars) + 1
