Jansen HS-22A62 Log splitter - 22t, Petrol powered - (Subtitled in English)

Описание: The Jansen HS-22A62 is a wood splitter in a class of its own. It has a real 22 tons splitting pressure and a very robust 6,5 PS OHV petrol engine.

The splitting pressure of our log splitters is measured directly at the splitting axe, so that this value corresponds to the actual splitting pressure. With many other suppliers, unrealistic values are given here, which are never achieved in practice.

A very big advantage of this device is that you can operate the splitter either standing or lying down!

This splitter is guaranteed to split any piece of wood and will not capitulate to any log. The length of the splitting piece can be up to 62 cm.

The splitter is very easy to operate. The motor is easy to start with a pull starter and starts very well even at sub-zero temperatures.

By means of a drawbar and towing device, the machine can be pulled to the place of operation with ease. The unit is not approved for use on the road behind a passenger car. The use behind an agricultural or forestry tractor would not require a road permit and would therefore be legal (please observe road traffic regulations - lights, number plate, etc.).

However, due to the small overall width of 105 cm, you can also transport the unit on a conventional trailer.

We will supply you with a splitting wedge with the splitting wedge mounted, free of charge, and a splitting wedge which is simply pushed over the splitting wedge. A change between wedge and cross is thus completed in seconds!

With the 30 cm long splitting wedge or splitting wedge, you can also open thicker logs with larger diameters in one operation. With shorter splitting wedges this often does not work and the log often has to be turned 180 degrees, which is very tedious.

The hydraulic system is designed so that the splitting wedge can be stopped in any position and moved forwards or backwards as required. The force is always applied and the splitting wedge does not have to be repeatedly moved upwards to the starting position, as is the case with many competitor products.

We have been selling these devices for many years and they have proven themselves with hundreds of customers. This log splitter will not fail on any piece of wood; also, no customer could ever bring us a piece of wood that this log splitter could not split.

The Jansen HS-22A62 is delivered with a high quality Kohler motor.


Kohler Motors
Since 1873, the American manufacturer Kohler has been building innovative engines, which are known worldwide for their excellent design and outstanding craftsmanship. Alongside Honda and B&S, Kohler is one of the leading brands when it comes to fitting small engines on garden and landscaping equipment and lawnmowers. Leading manufacturers such as John Deere, MTD, Stiga, Toro and many others use these high-quality engines. Kohler does not only build petrol engines - today the innovative Italian diesel engine manufacturer Lombardini is also part of the Kohler Group.


Technical data:
4 stroke engine OHV, 6,5 PS, 4,8 kW
Fuel: regular gasoline
Tank capacity: 3.6 litres
consumption: approx. 1.0 - 1.2 l/h
starter: pull-wire starter
Weight: approx. 270 kg without liquids
Train speed: max. 25 km/h
max. slit length: 62 cm
Cylinder speed for one pass downwards: approx. 8 sec.
splitting pressure: 22 tons (measured value)
diameter cylinder: 115 mm, piston rod = 45 mm
Splitting wedge, length: 30 cm (included)
Splitting wedge, length: 30 cm (included in delivery)
Packing dimensions: 191x50x66 cm (LxWxH)
Standing dimensions: 218x106x182 cm (LxWxH)
Dimensions horizontal: 220x106x128 cm (LxWxH)
Engine oil quantity: approx. 1 l (10W40 or 15W40)
Hydraulic oil quantity: approx. 9.5 l (HLP46)

(Translated from German)
