All about SWIR - In Ze Lab with Xavier Levecq, CSO Imagine Optic
Автор: Imagine Optic
Загружено: 2020-12-11
Просмотров: 670
Описание:
3 live demos in 1, featuring the 3 instruments that combine into a SWIR version of our optical metrology system, aka the "Swiss Army Knife of optics", built around the R-Flex2 technology.
We start with the characterization of a lens in the SWIR using the R-Flex2 SWIR, which combines a HASO4 SWIR or HASO4 SWIR 1550 wavefront sensor with a collimator and a light source.
Second comes aligning a lens in the SWIR with the HASO4 SWIR wavefront sensor with the help of the new SpotTracker technology. SpotTraker provides for absolute wavefront and tilt information, and alignment becomes as simple as pushing a glider and as literally as fast as 1,2,3.
Lastly we use the "Swiss Army Knife of optics" to characterize a large flat optics (a head-up display). Again, as fast as 1,2,3. Same goes for plugging the instruments together or disassembling them, hence the Swiss Army Knife idea for a tool that should cover over 80% of the needs of any optical engineer or scientist in SWIR metrology.
#metrology #optics #SWIR #SpotTracker #WavefrontExperts
