ALLPOWERS 100W Flexible Waterproof Solar Panels

Описание: ALLPOWERS 100W Flexible Solar Pannel
Model AP-SF-100
10% Off Discount Code:MarkYoung
ALLPOWERS SF100 Fleixble Solar Panel: https://bit.ly/4dRu9eP

Series VS Parallel - A Beginners Guide    • Series VS Parallel! A Beginner's Guide for...
Comes With
6 x Velcro straps
MC4 to XT60 connector
Key Features
Monocrystalline & ETFE panels (ethylene-tetrafluoroethylene copolymer)
Physical Specs
Length 39.4” / 1m
Width 23.6” / 0.6m
Thickness 0.12” / 3mm
Weight 5.5lbs / 2.5kg
Operating temp -20c to 85c
Waterproof IP68
Distortion angle complete U shape
Resistance pressure 50kg
Operating temperature -4F to 185F / -20C to 85C
 
Performance Specs
Max output 100w
Open voltage 30.6V
Short circuit current 4.58A
Max voltage 25.5V
Max current 4.17A
Max system voltage 120V

Connecting in Parallel or Series
Parallel
Output 200W
Max Current 8.34A
Max Voltage 25.5V
Short circuit current 9.16A
Open circuit voltage 30.6V

Series
Output 200W
Max Current 4.17A
Max Voltage 51V
Short circuit current 4.58A
Open circuit voltage 61.2V


Operation
Can be strapped to several surfaces
Can be attached by other means using grommets
Can be hooked up directly
Can be placed in series
Can be placed parallel
NOTES
Compare with Allpowers SF200 panel
Max output 200w
Open voltage 38.4V
Short circuit current 6.87A
Max voltage 32V
Max current 6.25A
Max system voltage 120V

Compare with Bluetti PV200
Maximum Power: 200W
Cell Lamination: ETFE (Ethylene Tetrafluoroethylene)
Cell Type: Monocrystalline Silicon
Cell Efficiency: Up to 23.4%
Open Circuit Voltage (OCV): 24.6V
Short Circuit Current (Isc): 10.8A
