EPLAN Cable & Cable Gland from A to Z: Device Selection to 3D Placement"

Описание: In this video I show you my complete cable workflow in EPLAN, from device selection all the way to clean 3D placement.

We start by selecting the right cable including accessories like cable glands directly in the device selection, no manual searching. EPLAN then automatically places the cores on the cable, and finally we place the cable gland with the correct tag in the 3D cabinet layout.

The result: A consistent, error-free schematic and a 3D model that's correct from the start.

What you'll learn in this video:

Assign cable and accessories via the device selection
Understand and use automatic core placement
Place cable glands with correct tags in the 3D cabinet layout


🔔 Subscribe for weekly EPLAN workflows

💬 Questions? Drop them in the comments
