Make Hinged 3D Models Easily in FreeCAD
Автор: Create With Tech
Загружено: 2023-08-27
Просмотров: 5047
Описание:
In this video I'll show you how you too can easily make 3D hinged models in FreeCAD. This is a relatively easy project that will teach you a bit about image manipulation for 3D printing as well as Computer Aided Design using FreeCAD.
Things You'll need:
1. FreeCAD (Official Release -- which I don't recommend)
https://www.freecad.org/downloads.php
2. FreeCAD (Realthunder version -- recommended)
https://github.com/realthunder/FreeCA...
3. Inkscape
https://inkscape.org/release/inkscape...
4. GIMP
https://www.gimp.org/downloads/
5. Download Hinge Files on Thingiverse
https://www.thingiverse.com/thing:284...
Music:
Music from #Uppbeat (free for Creators!):
https://uppbeat.io/t/hybridas/perfect...
License code: GGS1V86XT0EGE7EZ
00:00 - Introduction to PIP Hinged Models
02:07 - Create with Tech Intro
02:19 - What you'll need for project
04:16 - Getting useable image from web
06:51 - Fixing image for 3D printing in GIMP
13:05 - Converting image to SVG in Inkscape
18:40 - Converting image into a 3D model in FreeCAD
23:09 - Inserting hinges into cat in FreeCAD
47:09 - Checking model in PrusaSlicer
47:41 - Print timelapse & Outro
