cnc program G71 - G72 Full explanation Tamil / cnc machine operator Tamilnadu / cnc machine /
Автор: Mech life Tamil
Загружено: 2023-09-26
Просмотров: 6210
Описание:
Sample Program
@vtlcncking7
G28 U0 W0 G50 S1500
N1 T0101
M8 (OD FACING)
G96 S180 M3
G0 X255.0 Z5.0
G72 W2.0 R0.5
G72 P100 Q200 F0.25
N100
G0 Z0 G41 G1 X-2.0 F0.18
N200
G0 Z5.0 G40 X255.0
G28 U0 W0
N2 T0404
M8
(ID ROUGH)
G96 S180 M3
G0 X50.0 Z5.0
G71 U2.0 R0.5
G71 P500 Q600 U-0.5 W0.1 F0.25
N500
G0 X202.0
G41 G1 Z0 F0.12
X200.0 Z-10.0 X100.0 Z-30.0 X60.0 Z-45.0
N600
X50.0 G40 G0 Z5.0
G28 U0 W0
N3 T0505
M8 (ID FINISH)
G96 S220 M3
G0 X50.0 Z5.0
G70 P500 Q600 G0 X50.0 Z5.0
G28 U0 W0 M5
M9
M30
;;
G71 turning cycle is used for rough-material removal from a cnc lathe component. G71 turning cycle makes large diameter cutting easy. Cutting can be done in simple straight line or a complex contour can also be machined very easily.
Through G71 turning cycle parameters cnc machinists can control
Depth of cut.
Retract height.
Finishing allowance in x-axis and z-axis.
Cycle cutting-feed, spindle speed.
ParameterDescription
U=Depth of cut.
R=Retract height.
Second block
ParameterDescription
P=Contour start block number.
Q=Contour end block number.
U=Finishing allowance in x-axis.
W=Finishing allowance in z-axis.
F=Feedrate during G71 cycle.
S=Spindle speed during G71 cycle.
