ROTTNE H21D Harvester Demo Elmia Wood 2017

Описание: ROTTNE H21D Harvester Demo Elmia Wood 2017

ROTTNE H21D is the optimum final felling machine for those felling in really heavy forest.

ROTTNE H21D our new developed harvester, is built with 6 or 8 wheels and has a diesel engine with highly efficient exhaust emission control that fulfills the emission requirements of Tier 4 (FT4).Further on the harvester is equipped with a new hydrostatic transmission, which gives a tractive force of 230 kN, separate hydralic pumps for crane and head as well as a swivelling cab with an excellent view of the entire working area. In other words, a stable, reliable, modern harvester with high capacity.

http://www.rottne.com/en/skogsmaskin/...

Engine
Type JD 6090 HFC09, Power Tech PSS, Final Tier 4/FT4)
Output 227 kW (305 hp) at 1700 rpm
Torque 1351 Nm (996 lb ft) at 1500 rpm
Cylinder volume 9.0 litres (549 in3)
Diesel tank 500 litres (132 US gal)
Additional diesel tank 225 litres (60 US gal)
Transmission
Type D5 controlled, hydrostatic/mechanical with full capacity control. 3 gear steps. Manual differential locks.
Tractive force 230 kN (51 700 lbs)
Speed, gear 1 0 - 4 km/h (0-2.5 mph)
Speed, gear 2 0 - 7.5 km/h (0-4.7 mph)
Speed, gear 3 0 - 22 km/h (0-13.7 mph)
BRAKES
Type Dual-circuit el/hydraulic controlled neagtive wet disc brakes. Automatic load brake. Spring-assisted parking and emergency brake.
Wheel equipment
6 WD, front 750/45 x 30.5
6 WD, rear 700/70 x 34
8 WD 750/45 x 30.5
Chassis
Type Articulted frame
Steering angle +/- 43°
Max. steering touque 106 kNm (78 180 lb ft)
Horizontalangle +/- 24°
Hydraulic System
Pump capacity, loader 298 litres (79 US gal) / 1700 rpm
Working pressure, loader 3.0 - 25.0 MPa (425 - 3 625 psi)
Pump capacity, head 357 litres (94 US gal) / 1700 rpm
Working pressure, head 3.0 - 30.0 MPa (425 - 4350 psi)
Type Load-sensing system with double pumps, entirely separated from the transmission.
Degree of filtration 10 micron
Tank volume 217 litres (57 US gal)
Electrical System
Type 24 volt electrical system with CAN-bus technology.
Battery 2 x 145 Ah
Alternator 150 A
Machine control system ROTTNE D5
Bucking system ROTTNE Forester
Display 15
Working lights 22 pcs
Cab
Type Spacious, vibration-proof saftey cab. ISO certified.
Noise level 65 dBA
Swivels +/- 90°
Tiltable 15°, 14°, +/-11° (front, back, side)
Climate system ACC
Crane
Type Parallel knuckle boom loader, RK250, with tiltable swing base and 12.2 m (7.2 ft) telescope.
Tiltangle forwards 21°
Tiltangle backwards 20°
Lifting torque 325 kNm (239 700 lb ft)
Angle of rotation 250°
Reach 11 meters (33 ft)
Torque 62.4 kNm (46 020 lb ft)
Weight and dimensions
Service weight from 6WD: 24 200 kg (51 600 lbs) 8WD 26 700 kg (56 880 lbs)
Width 3 000 mm (118 in)
Length 9 233 mm (364 in)
Transportation height 3 722 mm (147 in)
Ground clearance (at articulated frame lock) 690 mm (27 in)
Equipment
Telescope Yes
Chains Yes
Lighting Xenon or LED Yes
Sprinklers Yes
Engine/cab heater Yes
Blinds Yes
Mobile telephone Yes
Vacuum pump Yes
Colour marking Yes
Reversing camera Yes
GPS/Geoinfo Yes
Filler pump Yes
Green oil Yes
Computer caliper Yes
Colour printer Yes
Mobile broadband Yes
Orbitrol steering Yes
Full toolkit Yes
Central lubrication Yes
Tracks Yes
Balanced bogie system Yes
Air compressor Yes
