(LITUO) BS5163 Resilient Gate Valve

Описание: Resilient wedge rising stem gate valve for water BS 5163 Rising stem resilient wedge gate valve is used the stem lifting the disc to control the open and close. It can see the open through the stem. Rising stem gate valves require enough installation space.
Website: www.watersvalve.com
Email: [email protected]
Product: https://www.watersvalve.com/product/b...


Youtube：
BS5150/ BS5163 resilient gate valve is one type of resilient seated gate valve with a flexible wedge gate as its on-off disc, whose moving direction is perpendicular to the flow.
The gate valve can be only fully open or fully close. BS5150/5163 type A cast iron resilient seated gate valves are widely used in a series of industries, especially in water supply projects, public works, water treatment plant, fire fighting, etc.
We can manufacture the BS5150 BS5163 resilient gate valve according to the standard of BS5150/BS5163 type A with sizes of 2″~24″ (DN50~600mm). Just feel free to contact us now to get the best prices. Big stock. Fast delivery.
Website: www.watersvalve.com
Email: [email protected]
Product: https://www.watersvalve.com/product/b...

Product Name: BS5163 Resilient Gate Valve
Diameter: 2”-32”/DN50-DN800
Pressure: PN1.0-1.6MPa
Body material: Ductile Iron
Connection: Flange
Body material: DI
Seat Materials: EPDM
Disc Materials: Ductile Iron+EPDM
Stem Materials: 2cr13stainless steel
Design standard: BS5163
Flange: BS4504 PN10.PN16/EN 1092
Face to face dimensions: BS5163
Test standard: BS5163
Work temperature: NBR≤80°,EPDM≤120°

Features:
Full bore design
BB bolted bonnet
OS&Y, outside screw, and yoke
Rising stem and non-rising handwheel
Resilient seated, metal seated, renewable seat rings
Available with gear operator

Application:
Water supply plant
High building industry
Mining, steel industry
Metallurgy plant, power plant
Oil, chemical industry
The textile, pharmaceutical industry
Wastewater, sludge, sewage treatment industry
Food, the pharmaceutical industry
