CRGO/CRNGO (silicon steel) Slitting Cutting Machine Line

Описание: variable frequency speed regulating slitting line (hydraulic pressure)Detonated industry revolution:
Contact: Owen ge, Email: transformercore99@ gmail.com , Mobile: +8618632727083
Site: http://www.qiaogexian. com/ ,Video: https://www.youtube. com/watch?v=1T7lHRJYcw4    / watch   v=atgTK1Kh-BY Facebook ID: https://www.facebook.com/ crgocuttingmachine whats app: +8618632727083

1 Thickness of roll slitting silicon steel sheet or low carbon steel sheet 0.2~0.5mm
2:Width of the rolling slitting sheet 40~1250mm
3:Strip Burr: ≦0.02mm
4:Width tolerance of strip burr ≦±0.2mm
5:Speed of slitting line 0~70M/min
6:Decoiler drum standard diameter Φ500mm
7:Recoiler drum standard diameter Φ500mm
8：Max load capacity of Decoiler ≦6T
9：Max load capacity of recoiler ≦6T
10：Max activity diameter of decoiler Φ530mm，
11 Min activity diameter Φ470mm。
12：Max activity diameter of recoiler Φ510mm，
13 Min activity diameter Φ470mm。
14：Guide pressure device working pressure 0.3-06Mpa

15 Outside diameter of the spindle for the roll slitting machine Φ120mm

16 Lifting height 350mm，

17V shape tray maximum load capacity of the lifting moving vehicle 6T。
17：General motor power32KW，
Decoiler,rolling cutting machine,recoiler AC motor driven by the frequency converter.
18：Total length 11m,width 5m,covering the area of 55 square meter.
19：Total weight 11T。

20：Working height level： 1M。
Main construction
1：6Ton Hydraulic pressing decoiler
2：6Ton hydraulic pressing recoiler
3、Variable frequency roll slitting machine
4、Double pneumatic guide pressing device
5：6Ton new type electric feed-in and feed-out lifting vehicle
6、Electric control panel
7、Hydraulic station
8、Grinding machine
9、 YG20 carbide scissors
★ The configuration of the sensor, length measuring device, intelligent digital display meter, the cutting length that required can be preset,(unit precision:0.1m) sound alarm when reaching the number.
