Beckhoff Servo Commissioning with EtherCAT coupler and I/O terminals
Автор: J Hahn
Загружено: 2020-12-02
Просмотров: 5711
Описание:
Main power: 1 phase 110~120VAC
Hardware:
1. 24VDC power supply;
2. Beckhoff industrial PC ;
3. Beckhoff servo drive AX5203;
4. Beckhoff EK1100 ethercat coupler and terminals(terminals are optional);
5. Beckhoff 1.45Kw servo motor AM8041-0E20-0000;
6. Main power cables;
7. Servo motor power supply cable;
8. Ethernet wire cable x 2;
9. Switches x 2;
10. Multimeter;
Software:
TwinCAT;
Document:
https://download.beckhoff.com/downloa...
Drive Order Link:
https://www.ebay.com/itm/164542023868
Motor Order Link:
https://www.ebay.com/itm/164547072646
EtherCAT Couple and IO Terminals Order Link:
https://www.ebay.com/itm/164547021139
